Name: Amplificador de sinal de alto desempenho 1800/2100/2600MHz para Repetidor de rede LTE Tri Band Repeater Amplificador
Brand: Shenzhen Atnj Communication Technology Co., Ltd.
SKU: AT-40-1800/2100/2600
Price: 2,425.00 USD
Availability: InStock

Amplificador de sinal de alto desempenho 1800/2100/2600MHz para Repetidor de rede LTE Tri Band Repeater Amplificador

5pcs

MOQ

USD+2300--2550+pcs

preço

Características Galeria Descrição de produto Peça umas citações

Características

Especificações

Faixa de frequência de 1800 MHz: 1710-1735 MHz/ 1805-1830 MHz

Faixa de frequência de 2100 MHz: 1920~1945/2110~2135MHz; 1945-1960/2135-2150MHz

escala de frequência 2600MHz: 2520-2535 MHz/2640-2655 MHz

Largura de banda 1800 MHz: 25 MHz

Largura de banda 2100 MHz: 25 MHz e 15 MHz

Largura de banda 2600 MHz: 15MHz

Portadores de RF ARFCN Filtragem: Digital

Conector do RF (clientes a escolher): N - tipo (fêmea)

Cobertura: 6000m2

Destacar:

Reforço de sinal de 2600 MHz

Reforço de sinal de três bandas

amplificador de sinal 1800/2100/2600mhz

Informação básica

Lugar de origem: China

Marca: ATNJ

Certificação: CE,ROHS，CCC，TUV,BV， ISO

Número do modelo: AT-40-1800/2100/2600

Documento: 10watt Digital Dual Band 18...40.pdf

Condições de Pagamento e Envio

Packaging Details: Standard neutral packing

Delivery Time: 25 work days

Payment Terms: T/T, Western Union,Paypal,Alibaba,Bank transfering.

Supply Ability: 1000+unit+per day.

Galeria

Amplificador de sinal de alto desempenho 1800/2100/2600MHz para Repetidor de rede LTE Tri Band Repeater Amplificador

Descrição de produto

High power Digital band selective 10Watt engineering cellular signal amplifier 40dBm repeater

1. High output 10W, stable fast speed signal, perfect for large area or high building signal improving
(can reduce device quantity, and for easy adjustment and maintain )

2. Pretty easy installation

3. Die cast aluminum alloy out shell for efficient heat dissipation, waterproof, dust proof, IP40 level;

4. Upgrade intelligent WTR chip integrated circuit, reduce the attenuation, with higher load, faster speed

5. Free settings depends on environment, coverage 6000sqm

Technical Specifications:

SPECIFICATIONS	PARAMETERS
Frequency Range	1800MHz	1710-1735MHz, 1805-1830MHz
	2100MHz	1920-1945MHz, 2110-2135MHz
	2100MHz	1945-1960MHz, 2135-2150MHz
	2600MHz	2520-2535MHz, 2640-2655MHz
Bandwidth	1800MHz	20MHz
	2100MHz	25MHz&15MHz
	2600MHz	15MHz
RF Carriers ARFCN Filtering	Digital
Gain	UL: 85±3 dB DL: 90±3dB
Output Power	UL: 25±2dBm DL: 40±2dBm
Automatic Gain Control	30dB/1dB
Minimum Input power	≥ -90dBm
Gain Flatness / PB Ripple	＜ 4dB
Automatic Level Control	≥ 25dB
EVM	≤8
VSWR	≤1.8
Noise Figure	≤8dB
Group Delay	≤10μs
RF Connector(Customers to Choose)	N -Type (Female)
Storage temperature range	-40°C to +85°C
Operating Temperature	-25°~+55°
Power Supply	195-265 VAC
Power consumption	≤100W
Barometric pressure	55 kPa -106 kPa
Environment Conditions	IP40
Relative humidity	5% - 95%
Weight	≤20kg
Size	596 x 400 x 203.5 mm

Product Description

Amplificador de sinal de alto desempenho 1800/2100/2600MHz para Repetidor de rede LTE Tri Band Repeater Amplificador 0

Amplificador de sinal de alto desempenho 1800/2100/2600MHz para Repetidor de rede LTE Tri Band Repeater Amplificador 5

Amplificador de sinal de alto desempenho 1800/2100/2600MHz para Repetidor de rede LTE Tri Band Repeater Amplificador 6

Amplificador de sinal de alto desempenho 1800/2100/2600MHz para Repetidor de rede LTE Tri Band Repeater Amplificador 7

Amplificador de sinal de alto desempenho 1800/2100/2600MHz para Repetidor de rede LTE Tri Band Repeater Amplificador 8

Shipping

●We will send your parcel as soon as possible after payment confirmed within 48 hours.

●Please provide your correct address,full name,and zip code.
●We generally would declare the parcel with lower value to avoid or lessen the Customs Tax.Import Tax is not including in the price. When it happens, it is buyers responsibility to pay for the tax and custom clearance.
●Shipping is out of our control. If you want to get the product fast, please choose fast shipping methods, like Fedex, UPS and DHL. If you find the package is beyond promised delivered time, please contact us, we will contact with the carriers and find out the reason.

FAQ

Q: Why choose us for cooperation?

A: We have the professional engineer to develop and make them suit for all over the world.we also will deal with all the problem when you have problem and reply to you at any time.

Q: Are you trading company or manufacturer ? Could I use our own logo and label?

A: We are the factory, with good trading service. We provide OEM/OEM service.

Q: What is your warranty time?

A: We promise 3-year warranty for all products shipped from us. Man-made sabotage and natural factors are not within the scope of
warranty.

Q: Can this mobile signal repeater create a signal where there is no cell signal before?

A: The mobile signal repeater cannot produce a signal, only amplify a weak one.

Q: Is it easy to set up your items?

A: Yes. We have a user manual and support technical support 24/7.
